Glass type
Glass type
THICKNESS | Single glass 4mm, 5mm, 6mm, 8mmLaminated glass 6.38mm, 8.76mm, 10.76mm, 12.76mm |
COLOUR |
|
REFLECTIVENESS |
|
SIZE | Minimum size: 210mmx297mm (0.0624sqm) Maximum size: 2250mmx3210mm (7.22sqm) |
For more technical information please download specification sheets (Schüco ADS 50NI and Schüco ADS 70HI):
Insulation type
Insulation type
- Acoustic: Double glazed glass helps to reduce noise levels to 29dB and, when combined with an acoustic PVB, it reduces them even further to 52dB in noisy and traffic-heavy environments.
GLASS TYPE | SPECIFICATION | NOISE REDUCTION LEVEL IN DB |
| Float glass | 4mm to 6mm | < 29dB |
| Laminated glass | 6.38mm to 12.76m | < 33dB |
| Standard Double glazing | Depends on unit configuration | 29dB to 40dB |
| Double glazing +laminated glass | Depends on unit configuration | 34dB to 46dB |
| Double glazing +laminated glass + acoustic pvb | Depends on unit configuration | 38dB to 52dB |
- Thermal : The special engineering of our double-glazed solutions, called IGU processing, helps reduce the amount of heat passing between glass panes. Select from a range of UG performance levels (low to high) to customise your insulation.
Surface / coating type
- Solar Control: We can customise surface/coating types based on your thermal insulation and/or solar control requirements. We offer two different solar control customisations, either magnetron (offline) which is soft coated or pyrolytic (online) which is hard coated.
Below is a comparison table showing how a Low-E coating greatly affects the energy efficiency of insulated glazing and their respective Ug value.
GLASS CARTEGORY | GLASS TYPE | THERMAL TRANSMITTANCE (Ugvalue)W/ m2K | ENERGY EFFICIENCY % |
| Standard | Float glass | 5.0 to 5.8 | 1.0% |
| Efficiency 01 | Double glazing + air cavity | 2.8 to 3.0 | 44% |
| Efficiency 02 | Double glazing + argon gas+ low-E coating | 1.2 | 76% |
| Premium | Double or Triple glazing + argon gas+ low-E coating | 0.9 to 1.0 | 82% |
- Privacy film: Due to its high level of reflectivity, our coated glazing units can also provide enhanced levels of privacy for those who need it.
- Smart film: Instantly transform a common area into a private space with our Electric Smart Film. Switch from clear glass to frosted glass using an electronic charge, creating privacy and easy light control whenever you need it.
Safety features
Safety features
- Fire rated: Our entire EVONIGGLASS range can be customised for fire-proofing. We can install our safety-first and innovative fire-resistant windows and doors throughout an entire building or in a single area depending on your requirements. Fully certified and compliant with European safety standards, we’re ready to protect your space.
- Bullet-proof: Our ballistic-resistant glass provides protection to any residential or commercial building that is considered high-risk. Designed with personal safety in mind, our bullet-resistant glass can be installed both inside and outside, in a single room or throughout an entire building.
Choice of bullet resistance | Choose from class level threat BR1 to BR7. |
30-minute fire protection | Provides protection against blazes for 30 minutes. Perfect for installing on fix light windows and curtain walls. |
60-minute fire protection | Provides protection against blazes for 60 minutes. Perfect for all doors and closer windows. |
90-minute fire protection | Provides protection against blazes for 90 minutes via special infill in the profile. Perfect or specialised use in locations like hospitals. |
Hard-wearing | Effective at both close and long range |
Full security | Offering protection against a range of firearms. |
- Shatter Proof / Anti-Theft: The EVONIGGLASS range can be customised with a laminated security glass solution that provides breakproof durability and resistance against damage and theft.
